ALFA Network AHMB7292S IEEE 802.11ah sub 1 GHz module with mikroBUS™ form factor Newracom™ NRC7292
Pickup available at 2251 NW 41st Street
Usually ready in 1 hour
AHMB7292S is world's first WiFi HaLow™ module for mikroBUS™
The AHMB7292S module series allows building long range, ultra-low power WiFi networks in sub 1 GHz license-exempt bands. WiFi HaLow™ enables connectivity for many applications, including sensors and wearables.
With support for standalone and host based modes, up to 15 Mbps data throughput and complete SDK, getting started with this new WiFi standard will be straightforward.
- Newracom™ NRC7292 WiFi HaLow™ SoC (IEEE 802.11ah draft 8.0 compliant)
- Qorvo™ RFFM6901 front-end
- IPEX/U.FL antenna connector
- mikroBUS™ M-size form factor
- Connectors for UART and mode select
- 3× LEDs
Specifications :
Part/Model #: AHMB7292S Newracom NRC7292
Country of Origin: Taiwan
Manufacturer : Alfa Network Inc.
Sales tax is required in many states and will be added at checkout if applicable to your delivery state. Tax exempt forms can be sent to our support department.
| Chipset | Newracom™ NRC7292 |
| Frequency | 847 MHz (TW) 866 MHz (EU) 915 MHz (US) 922 MHz (KR) 924 MHz (JP) |
| Modulation | OFDM with BPSK, QPSK, 16QAM, 64QAM |
| Data rate | 150 Kbps ~ 15 Mbps |
| Channel bandwidth | 1/2/4 MHz |
| Antenna connector | 1× IPEX/U.FL |
| Interfaces | SPI UART I2C |
| LED | 1× power 1× TX 1× RX |
| Form factor | mikroBUS™ M-size |
| Dimensions | 25.4 × 42.9 × 3.0 mm (without headers) |
| Software | https://github.com/newracom/ |
Shipping & Returns
We are in Florida and ship to: USA, Australia, Austria, Canada, France, Germany, Israel, Netherlands, and the United Kingdom. Local pickup available in Gainesville, FL
Expedited shipping orders placed before 3PM EST weekdays will ship that day. Standard shipping orders ship within 1 business day.
Sales tax: shipments shipped to states in which we are registered to collect tax will have appropriate tax added at checkout. Tax exempt forms can be sent to our support staff who can activate exemption status.
Lost packages and insurance
International Shipping:
Shipping options are visible in cart by using the shipping estimator. Transit times posted are estimates. International packages are subject to customs holds and duty payment may be required by your government on delivery. The cost of duty is not reimbursable. Internatonal shipping charges are not refundable in the event of a return.
Returns
See item description for product specific return policies, and return policies vary by item.
Bulk/High Value Order Returns
Due to the labor required to package and ship bulk orders, as well as cost and stock issues involved in replenishing items, bulk orders of 5 pieces or more are not returnable unless the equipment is defective or mis-advertised, or a return period is prenegotiated. For non-defective returns over $500, a restocking fee may be deducted from the refund to cover bank or card processing fees.
Backorder/Preorder
Items on backorder or preorder will ship as estimated on the item page. You can cancel an order any time up until shipment. Orders with expedited shipping will arrive in the advertised time after the order ships, not after the order is placed.
Cancellations
If you want to cancel an order, please email or call us at (352) 372-9902. If your item has not been shipped, we will cancel the order and provide a full refund.
Compatibility
Microsoft Windows 7, 8, 10, 11, Linux Kernel 4.19 or later
