Rokland

Meshtastic™ compatible 5.8 dBi N-Male Omni Outdoor 915 MHz Antenna kit with 6, 10, 15 or 25' cable choice

$49.97
Cable Length: 6 foot SMA male to N-female

Pickup available at 2251 NW 41st Street

Usually ready in 1 hour

Perfect for Meshtastic users, and users of other hardware with SMA female connectors that operate in the 900-930 frequency range.

This kit includes our white fiberglass Rokland 5,8 dBi 915 MHz low profile 32" fiberglass IoT antenna with an N-female connector and U-bolt bracket mount.

Choose from the menu above if you want 6 foot cable, 10 foot, 15 foot, or a 25 foot. The cable for 6, 10, and 15" length is a 240 grade low-loss shielded, and the connector will fit this antenna. The other end is a SMA male connector that will connect to most Meshtastic items. The 25 foot length is a thicker shielding called 400 grade to help insulate against dB loss from the longer cable length. 240 cable has a diameter of .24/inch and 400 grade is .4/inch.

Note this is not for Helium, as Helium miners use an RP-SMA connector which is different.

This is certified and designed for outdoor environments and is weatherproof. Using less fiberglass, the antenna costs less to manufacture and ship, resulting in savings. Plus it has better wind resistance due to its smaller surface area.

This antenna is compatible with IoT devices that use the 915 Mhz frequency or 900-930 Mhz range.

 Full Spec Sheet

  • 5.8 dBi gain 915 MHz band antenna for LoRa and HaLow™ long-distance low data transfer industrial application (this is NOT a 2.4 or 5 GHz WiFi antenna).
  • 35-degree vertical beamwidth, 360 degree horizontal, N-male connector. VSWR ≤ 2 with 5.8 dBi gain, 50-ohm impedance, max input power 50 W, made of Fiberglass, Copper, and Aluminum Alloy
  • 32 inches heightLearn more about antenna size and gain correlation
  • Includes U-bolts and mounting bracket as pictured, plus antenna. Does NOT include a pole to mount to as shown in the picture. Pole shown in images with the antenna mounted are just for demonstration purposes
  • This is NOT a WiFi antenna or 4G cellular antenna, it is ONLY for 915 MHz sub 1 GHz HaLow or LoRa application, or other application this band.

Questions about miners, antennas, and cables? Visit this page to learn more

We do recommend RokTape to seal all outdoor connection points.

Specifications:
900-930 MHz frequency
35 degree vertical beamwidth

360 degree horizontal beamwidth
N-Male connector on antenna (female on cable choice)
SMA male connector on other end of cable
VSWR: ≤ 2
5.8 dBi gain
50 ohm impedance
Max input power: 50 W
Wind Rating: 60 m/sec
Operating Temperature: -58F to 176F
Height: 32 inches
Made of Fiberglass, Copper, and Aluminum Alloy
